HD Tune Pro 3.5 READ / WRITE Drive Benchmark	Source: HD TUNE

HD Tune Pro is an extended version of HD Tune which includes many new features such as: write benchmark, secure erasing, AAM setting, folder usage view, disk monitor, command line parameters and file benchmark. The benchmark measures raw performance in a couple different ways to measure a hard drive for Read and Write tests, which are conducted separately. To read the results below consider that highest minimum/maximum/average transfer rates are better, while lower (quicker) access times are best. Lastly, highest burst rates are better.

HD Tune 4.01 - Read Tests Read Average Transfer Rate: (MB/s) Points Ranking Western Digital RE4 1TB WD1003FBYX HDD 111.8 Western Digital RE4 1TB WD1003FBYX HDD (RAID 0) 215.2 Western Digital RE4 1TB WD1003FBYX HDD (RAID 1) 107.6 Western Digital 1TB WD1001FALS HDD 86.1 Western Digital 1TB WD1001FALS HDD (RAID 0) 165.1 Western Digital 1TB WD1001FALS HDD (RAID 1) 86 OCZ Vertex 2 128GB SSD 233.1 Plextor PX-128M1S SSD 100.1 Seagate 3TB Barracuda XT HDD 117.5 Seagate 2TB Barracuda XT HDD 110.2 Seagate 750GB Momentus XT SSHD 90.7 Seagate 500GB Momentus XT SSHD 84 Read Access Time: (ms) Points Ranking Western Digital RE4 1TB WD1003FBYX HDD 12 Western Digital RE4 1TB WD1003FBYX HDD (RAID 0) 12.4 Western Digital RE4 1TB WD1003FBYX HDD (RAID 1) 12.5 Western Digital 1TB WD1001FALS HDD 12.2 Western Digital 1TB WD1001FALS HDD (RAID 0) 10.1 Western Digital 1TB WD1001FALS HDD (RAID 1) 10.2 OCZ Vertex 2 128GB SSD 0.056 Plextor PX-128M1S SSD 0.3 Seagate 3TB Barracuda XT HDD 26.8 Seagate 2TB Barracuda XT HDD 16.6 Seagate 750GB Momentus XT SSHD 0.615 Seagate 500GB Momentus XT SSHD 16.9 Read Burst Rate: (MB/s) Points Ranking Western Digital RE4 1TB WD1003FBYX HDD 176.5 Western Digital RE4 1TB WD1003FBYX HDD (RAID 0) 3536 Western Digital RE4 1TB WD1003FBYX HDD (RAID 1) 3370.6 Western Digital 1TB WD1001FALS HDD 134.4 Western Digital 1TB WD1001FALS HDD (RAID 0) 143.6 Western Digital 1TB WD1001FALS HDD (RAID 1) 144.7 OCZ Vertex 2 128GB SSD 216.8 Plextor PX-128M1S SSD 101 Seagate 3TB Barracuda XT HDD 367.6 Seagate 2TB Barracuda XT HDD 312.4 Seagate 750GB Momentus XT SSHD 155.9 Seagate 500GB Momentus XT SSHD 183.5

In HDTune the 1TB Western Digital RE4 achieves a READ Burst Rate of "3536.6MB/s" and an Average Read transfer rate of 111.5Mb/s. Max Read Transfer rate is 138MB/s, access time is 12ms. In RAID 1 mode the drives are a hair slower at 107.6MB/s average transfer rate. RAID 0 does what you'd expect, boosting average read transfer rate up from 111MB/s to 215MB/s.
