Shuttle XPC SG33G50 Intel G33 Express SFF PC Review
Shuttle XPC SG33G50 Intel G33 Express SFF PC Review - PCSTATS
In this review, PCSTATS will be testing out Shuttle's glossy-black XPC SG33G50 small formfactor barebones PC. Like all barebones computers, the Shuttle XPC SG33G50 includes the case, motherboard, CPU heatsink and powersupply.
 82% Rating:
Filed under: Computer / SFF PCs Published:  Author:
External Mfg. Website: Shuttle Dec 07 2007   C. Sun
Home > Reviews > Computer / SFF PCs > Shuttle XPC Shuttle SG33G50

Prelude to Benchmarks and Test Specs

As the Intel G33 Express chipset is Microsoft Windows Vista ready, PCSTATS will be testing the Shuttle XPC SG33G50 SFF system in Windows Vista 32 bit. Consequently there are slightly less benchmarks than we would normally have for a WindowsXP based test system because benchmark compatibility with Vista is still finding its feet.

The details of how the Shuttle XPC SG33G50 SFF system test system was configured for benchmarking; the specific hardware, software drivers, operating system and benchmark versions is indicated below. In the second column are the general specs for the reference platforms this Intel G33 Express based motherboard is to be compared against.

Please take a moment to look over PCSTATS test system configurations before moving on to the individual benchmark results on the next page.

In the last year or so PCSTATS has tested quite a few SFF PC's but none will be compared to the Shuttle XPC SG33G50 because the system and test parameters are different. If you're interested in the small systems, you'll want to check out our reviews on the MSI MEGA mPC 945, Biostar iDEQ 250N, Shuttle XPC SN27P2 and the two tiny AOpen miniPC MP915-B Super Multi and Mini PC MP945-VX Ultra small SFF reviews.

PCSTATS Test System Configuration
test system intel reference system reference system #1 reference system #2
processor: intel Core 2 Duo E6750 Intel Core 2 Duo E6600 AMD Athlon64 X2 5000+ (AM2) AMD Athlon64 FX-60 (Socket 939)
Clock Speed: 8 x 333 MHz = 2.67 GHz 9 x 266 MHz = 2.4 GHz 13 x 200 MHz = 2.6 GHz 13 x 200 MHz = 2.6 GHz
Motherboard: Shuttle XPC SG33G50(Intel G33 Express) ECS G33T-M2 (Intel G33 Expresss)

Biostar TF7050-M2 (GF 7050PV)
MSI K9AGM2-FIH (AMD 690G)
Albatron KM51PV-AM2 (GF6150)
ECS AMD690GM-M2 (AMD 690G)

Asus A8N-VM (GF 6150)
Videocard: Onboard Intel GMA 3100 MSI NX8800GTS-T2D320E-HD-OC
Memory:

2x 1024MB Corsair Twin2X2048-6400C4

2x 1024MB Corsair Twin2X2048-8888C4DF

2x 1024MB Corsair Twin2X2048-6400C4

2x 1024MB Patriot PDC2G4000ELK
Hard Drive: 74GB Western Digital Raptor WD740
CDROM: AOpen Combo 52x
PowerSupply: Shuttle 250W PSU PC Power & Cooling TurboCool 510 SLI
Heatsink: Shuttle Custom Heatsink Intel Reference AMD Athlon64 FX-62 Reference
Software Setup:

Microsoft Windows Vista Ultimate
nVIDIA Forceware 15.00
ATi Catalyst 7.4
nVIDIA Forceware 158.18

Benchmarks: SYSMark 2007 Preview
SiSoft Sandra XIb
PCMark05
3DMark06
Doom 3

FEAR
