Processor
|
|
Supports Socket A for AMD Athlon
and Duron Processors
Supports Athlon Processors from 700 MHz to 1.6 GHz and Higher
Supports Duron Processors from 600 MHz to 950 MHz and Higher
Supports Adjustable Vcore & VIO Function
3-Phase Power Solution
Provides 46A Power for Future high Frequency Athlon Processor
|
|
Chipset
|
|
VIA Apollo
KT133A chipset
VIA VT82C686B chipset
AMI ATA/100 IDE RAID (KK266Plus-R)
C-media CMI8378 MX Sound Chip(with 6 channel and
SPDIF)
|
|
Bus Frequency
|
|
Supports DDR266/200
MHz FSB
MicroStepping IWILL CPU frequency setting
Bye-Bye Jumper IWILL Smart Setting
|
|
System Memory
|
|
3 x DIMM sockets up to 1.5GB
Supports PC-133 / PC-100 SDRAM / Supports VCM memory types
Supports 64/ 128/ 256/ 512MB SDRAM modules
Supports 3.3V unbuffered / registered DIMMs
|
|
On Board IDE
|
|
Dual
Ultra DMA 100/66/33 IDE Ports
Supports ATAPI IDE CD-ROM, ZIP-100 & LS-120
|
|
Audio
|
|
Supports 6 channel speakers
32-voice HRTF-base 3D positional audio
Supports Microsoft DirectSound 3D and Aureal A3D
Supports EAX sound effects (Environment Audio eXtension)
Supports SPDIF (via IWILL SuperAudio ) (Optional)
|
|
Expansion Slots
|
|
1 x ACR Slot
1 x ISA slot
1 x AGP universal connector
6 x PCI 2.2 Bus Master Slot
4 x ATA/100 UDMA IDE channel(KK266Plus-R only)
|
|
I/O Interface
|
1 x SMBus Header
1 x FDD
1 x Parallel port
2 x PS/2 connectors for mouse and keyboard (Supports Auto Swapping)
1 x Internal IR Connector
2 x Serial ports
1 x Game/MIDI port
4 x USB ports (2 x internal)
|
|
BIOS
|
|
2 Mbit EEPROM with Flash Protection
"Bye-Bye Jumper" IWILL Smart Setting
PC99 Compliant
Supports Plug and Play (PnP)
Supports APM 1.2
Supports DMI 2.1
Supports ACPI
1.0
|
|
Power Management
|
|
Wake on LAN(WOL)
Wake on Modem
RTC Alarm
Window2000/98/95 power off
|
|
Board Size
|
ATX Form Factor - 305mm X 240mm (6
Layer PCB)
6 channel audio - 100mm X 28mm
|
